Telescoping Home Bed Rail
6631
Item
Number
Part Number
DescriptionNote
Quantity Per
Package Assembly
1135777 Kit, Telescoping Bed Rail 1 21 A,B
Washer, Nylon (3/16 x 7/16 x 1/8") 1 22
Rivet (3/16 x 7/16") 1 23
Pin, Plunger 1 24
Spring, Plunger (23/64 x 5/8") 1 25
Plug Button, Grey (7/8") 1 26
Knob, Plunger, Grey 1 27
Rail, Telescoping - Outside 1 18
Rail, Telescoping - Inside 1 19
Label, Entrapment Warning 1 1
1022789-NLA NLA - Tube, Channel with Barrel - Left Head End /
Right Foot End
1 210
1022790-NLA NLA - Tube, Channel with Barrel - Left Foot End /
Right Head End
1 210
1023599-NLA NLA - Tube, Channel, Chrome - Center 1 211
40188X009 Button, Single Snap 1 412
A - As of 10/17/03 the rails have 4 rungs instead of 3 so an inner and an outer Rail needs to be ordered when replacing.
B - Includes: Items 2-9 and the Warning Label
NOTE:
24
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
