Invacare Etude - Operating the Etude with 4-section Mattress Support

12
6. Operating the Etude
TM
with 4-section mattress support
The bed can be equipped with this type of hand control: (Soft Control)
Or with this type of hand control: (HB 70)
Backrest up
Button with the symbol shown
above.
Push the left-hand side of the button.
Backrest down
Button with the symbol shown
above.
Push the right-hand side of the button.
Thigh section up
Button with the symbol shown
above.
Push the left-hand side of the button.
Thigh section udown
Button with the symbol shown
above.
Push the right-hand side of the button.
Height up
Button with the symbol shown
above.
Push the left-hand side of the button.
Height down
Button with the symbol shown
above.
Push the right-hand side of the button.
Height adjustment of the bed UP/DOWN
Sitting position, irrespective of present position
Horizontal mattress support, irrespective of present position
“Out of bed button”- Raises the backrest and brings the thigh section to
horizontal
Raises the thigh section and brings the backrest to horizontal
