7. Operating the Etude
TM
with 3-section mattress support
The bed can be equipped with this type of hand control: (Soft Control)
Or with this type of hand control: (HB 70)
Backrest up
Button with the symbol shown
above.
Push the left-hand side of the button.
Backrest down
Button with the symbol shown
above.
Push the right-hand side of the button.
Height up
Button with the symbol shown
above.
Push the left-hand side of the button.
Height down
Button with the symbol shown
above.
Push the right-hand side of the button.
Both 3 - and 4 - sectioned beds can be equipped with hand controls that activate the tilt of the mattress support.
The tilt function must only be operated by medically trained persons - otherwise, there is a risk of
injury to the patient´s health.
Hand controls with tilt activating can be ordered from Invacare® - please refer to the section "Order numbers for
accessories".
Height adjustment of the bed UP/DOWN
Horizontal mattress support, irrespective of present position
“Out of bed button”- Raises the backrest and brings the thigh section to
horizontal
