6 DEALER SECTION - PACKAGING, HANDLING, AND SET-UP
Invacare
®
G5510 Bed 44 Part No 1180159
Unpacking Foot and Head Sections
1. Remove any loose packing from the carton.
2. Foot Section carton includes: One Foot End Section (electric beds include pendant, power supply with power cord, and head, foot and hi/lo
motors with cables), and one emergency crank handle. Only frame members should be gripped on the foot section for handling.
3. Head Section carton includes: One Head End Section. Any part of the head section may be gripped for handling.
FIGURE 2 Unpacking Foot and Head Sections
Shipping Carton
Inserts
Head End
Section
Insert
Insert
Insert
Power Supply
Foot End Section
Shipping
Carton
Pendant Cable
Insert
