Invacare Leo - Removing;Fitting Tyres (Castor Wheel of 3-Wheel Version)

72
For a description of the procedure for repairing a tyre, see section "Mending punctures" on page
74.
11.1.2 Removing/fitting tyres (castor wheel of 3-wheel version)
WARNING: Lifting the vehicle by the plastic cladding may cause damage to the cladding.
• Only lift the vehicle by the chassis.
Required items:
• 12 mm spanner
• 13 mm spanner
• 13 mm safety nut
Removing the tyres
• Lift the vehicle at the front of the chassis and tip it
backwards with the anti-tipper wheels until it is lying on the
backrest.
• Remove the wheel safety nut (1) using the 13 mm spanner.
Counterhold the bolt (2) using the 12 mm spanner.
• Remove the bolt.
• Remove the wheel together with the spacers and the
washer.
