To Next PageTo Next PageWhat does Error Code E28 mean on Invacare MK5 EX Wheelchair joystick?
If your Invacare Wheelchair displays error code E28, and the MPJ joystick is on or flashes 5 times, or it is a DPJ joystick, the system might be tilted, reclined, or elevated beyond drive lock-out angle (20°). Return to neutral position (upright and completely lowered). Check limit switch setting.
What to do if Invacare Wheelchair does not respond to commands?
If your Invacare Wheelchair isn't responding to commands, the issue might stem from a poor battery terminal connection (ensure terminals are clean), a bad joystick connection (check all connections), or a faulty wiring harness connection or blown fuse (replace wiring harness). Refer to the wheelchair Owner’s Manual for guidance.
Why does Invacare Wheelchair veer to the left or right?
If your Invacare Wheelchair veers to the left or right on a level surface, the joystick likely needs calibration. You can calibrate the joystick with a programmer. If calibrating doesn't solve the issue, the joystick may need to be replaced. Refer to Joystick Throw on page 25 for calibration information.
What does Error Code E14 mean on Invacare Wheelchair?
Error code E14 on your Invacare Wheelchair indicates that the batteries need to be charged. Charge the batteries following the instructions in the wheelchair Owner’s Manual.
What does Error Code E28 mean on Invacare MK5 EX?
Error code E28 on your Invacare Wheelchair means that the battery charger is connected. Unplug the battery charger from the wheelchair. Refer to the wheelchair Owner’s Manual for information about the battery charger.
What causes incorrect switch response on Invacare MK5 EX Wheelchair?
An incorrect switch response on your Invacare Wheelchair is caused by a programming error or a bad switch. Use the programmer to verify TRECM programming. Save the proper standard program to reset switch functions.
Why is my Invacare MK5 EX slow when seat is elevated?
If your Invacare Wheelchair slows or stops while driving and the DPJ Joystick - ORANGE LED flashes or MPJ Joystick - “SLOW” is displayed, it's likely because the elevating seat is elevated. The elevating seat has a speed reduction safety mechanism that slows the wheelchair's speed by 80% when the seat is elevated. Return the seat to its lowest position.
Why are there no LEDs on Invacare MK5 EX Wheelchair joystick?
If there are no LEDs on your Invacare Wheelchair joystick, it could be due to the joystick connection to the controller being unplugged or damaged (check all joystick connections, replace if damaged) or corroded wiring or connections (replace wiring harness). Refer to the wheelchair Owner’s Manual.
Why is my Invacare MK5 EX programmer not working?
If the programmer for your Invacare Wheelchair does not work or gives a “communication error”, the system might be tilted, reclined, or elevated beyond the drive lock-out angle (20°). Return to neutral position (upright and completely lowered). Use the programmer to check the Current Status Menu, particularly the drive lock-out setting. To adjust drive lock-out angle. To turn drive lock-out on or off.
Why is my Invacare MK5 EX Wheelchair actuator speed too fast?
If the actuator speed on your Invacare Wheelchair is too fast, it is likely due to a programming error. Check TRECM programming to confirm the speed setting for the desired actuator.
Provides critical warnings and cautions for initial setup and operation of the wheelchair.
Details important notices, user responsibilities, and recommendations regarding restraints.
Lists technical details including seat dimensions, ranges, and weight limitations.
Specifies that Invacare-certified individuals must perform setup and tuning to avoid voiding the warranty.
Covers general warnings on operation, electrical safety, grounding, and extension cords.
Recommends battery types and lists general cautions for operation, reaching, and balance.
Addresses weight training, tire pressure, weight limitations, and general operational warnings.
Warns about potential interference from radio wave sources affecting wheelchair operation.
Details safe handling, stability, balance, and coping with everyday obstacles.
Provides safety precautions for moving wheelchairs on stairs and warns against escalator use.
Covers safe transferring techniques and highlights specific pinch points.
Provides a checklist for regular inspection of electrical, drive, tilt, recline, and arm components.
Details inspection for armrests, cushions, and provides a troubleshooting guide for common issues.
Covers warnings for tilt operation, drive lock-out, and approved actuator controls for tilt functions.
Explains how to use single function and optional four-way toggle switches for tilt adjustments.
Covers warnings for recline operation, drive lock-out, and approved actuator controls for recline functions.
Provides instructions for adjusting the recline angle using the four-way toggle switch.
Covers warnings for tilt/recline operation, drive lock-out, and approved actuator controls.
Explains how to adjust tilt and recline angles using toggle switches and notes on drive lock-out.
Details how to use the ventilator tray, including weight capacity and securing procedures.
Explains Vernier Shear Reduction (VSR), its function in reducing user shear during recline.
Provides instructions for operating Vernier Shear Reduction (VSR) independently of the recline function.
Covers installation, removal, and adjustment of mechanical and genius legrests.
Details installation, removal, and adjustment of power legrests, including footplate and calfpad.
Explains detailed adjustments for footplate depth, angle, and calfpad height/width for power legrests.
Covers warnings, pinch points, and instructions for removing and installing reclining armrests.
Provides a step-by-step guide for adjusting the height of the armrests.
Covers removal, installation, height, depth, and direction adjustment of the headrest.
Details the process for replacing the headrest, including screw removal and reinstallation.
Provides critical warnings and cautions for initial setup and operation of the wheelchair.
Details important notices, user responsibilities, and recommendations regarding restraints.
Lists technical details including seat dimensions, ranges, and weight limitations.
Specifies that Invacare-certified individuals must perform setup and tuning to avoid voiding the warranty.
Covers general warnings on operation, electrical safety, grounding, and extension cords.
Recommends battery types and lists general cautions for operation, reaching, and balance.
Addresses weight training, tire pressure, weight limitations, and general operational warnings.
Warns about potential interference from radio wave sources affecting wheelchair operation.
Details safe handling, stability, balance, and coping with everyday obstacles.
Provides safety precautions for moving wheelchairs on stairs and warns against escalator use.
Covers safe transferring techniques and highlights specific pinch points.
Provides a checklist for regular inspection of electrical, drive, tilt, recline, and arm components.
Details inspection for armrests, cushions, and provides a troubleshooting guide for common issues.
Covers warnings for tilt operation, drive lock-out, and approved actuator controls for tilt functions.
Explains how to use single function and optional four-way toggle switches for tilt adjustments.
Covers warnings for recline operation, drive lock-out, and approved actuator controls for recline functions.
Provides instructions for adjusting the recline angle using the four-way toggle switch.
Covers warnings for tilt/recline operation, drive lock-out, and approved actuator controls.
Explains how to adjust tilt and recline angles using toggle switches and notes on drive lock-out.
Details how to use the ventilator tray, including weight capacity and securing procedures.
Explains Vernier Shear Reduction (VSR), its function in reducing user shear during recline.
Provides instructions for operating Vernier Shear Reduction (VSR) independently of the recline function.
Covers installation, removal, and adjustment of mechanical and genius legrests.
Details installation, removal, and adjustment of power legrests, including footplate and calfpad.
Explains detailed adjustments for footplate depth, angle, and calfpad height/width for power legrests.
Covers warnings, pinch points, and instructions for removing and installing reclining armrests.
Provides a step-by-step guide for adjusting the height of the armrests.
Covers removal, installation, height, depth, and direction adjustment of the headrest.
Details the process for replacing the headrest, including screw removal and reinstallation.
General| Frame Material | Steel |
|---|---|
| Wheel Size | Front: 20 cm (8 in) |
| Armrests | Fixed |
| Footrests | Swing-away |
| Weight Capacity | 125 kg (275 lbs) |
| Seat Width | 40 cm (16 in), 45 cm (18 in), 50 cm (20 in) |
| Seat Depth | 40 cm (16 in), 45 cm (18 in) |
