Invacare MK5 EX - RECLINE ONLY OPERATIONS; OPERATING RECLINE ONLY SYSTEMS; INCREASING;DECREASING RECLINE ANGLE

Tilt/Recline Seating Systems® 20 Part No. 1114822
This Section Includes the Following:
Operating Recline Only Systems
OPERATING RECLINE ONLY SYSTEMS (FIGURE 1)
WARNING
NEVER operate the wheelchair while in any recline/back angle combination
over 20
o
RELATIVE TO THE VERTICAL POSITION. If the drive lock-out
does not stop the wheelchair from operating in a recline/back angle combi-
nation 20
o
RELATIVE TO THE VERTICAL POSITION, DO NOT operate
the wheelchair. Have the wheelchair serviced by a dealer or qualified tech-
nician.
Reduced recline limits apply with optional vent tray. Refer to MK5 EX and
MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part num-
ber 1114808.
Use only TAC, SAC, TRSS and TRCM actuator controls to activate the tilt/
recline functions. DO NOT USE any other actuator controls. Such devices
may result in excess heating and cause damage to the actuator and associated
wiring and could cause a fire, death, physical injury or property damage. If such
devices are used, Invacare shall not be liable and the limited warranty is void.
A NOTE ABOUT DRIVE LOCK-OUT
Drive lock-out is a safety feature designed to prevent the wheelchair from being driven
while in any recline/back angle combination over 20
o
RELATIVE TO THE VERTICAL
POSITION. When the drive lock-out feature has been activated, the LED on the four-
way toggle switch will light.
INCREASING/DECREASING RECLINE ANGLE
NOTE: The recline angle range is from 95
o
to 175
o
with a 5
o
seat-to-floor angle. The recline angle
range is from 90
o
to 175
o
with a 0
o
seat-to-floor angle.
1. Make sure the wheelchair is on a level surface.
2. Pull the four-way toggle switch back towards the rear of the wheelchair until the
desired recline angle is achieved.
NOTE: If the wheelchair is equipped with switch options, scan to the correct ECU or Auxiliary
Mode, then activate the control device in the corresponding reverse direction to operate the
recline function. Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL,
part number 1114808, for complete switch option operating instructions.
3. Release the four-way toggle switch to the neutral position.
NOTE: The four-way toggle switch will alternate functions (increase recline angle, decrease
recline angle) after it has been released to the neutral position for a minimum of one (1) second.
NOTE: Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
number 1114808 for complete four-way toggle switch operating instructions.
