Part No. 1114822 19 Tilt/Recline Seating Systems®
TILT ONLY SECTION 3
FIGURE 1 - OPERATING TILT ONLY SYSTEMS
NOTE: If the wheelchair is equipped with switch options, scan to the correct ECU or Auxiliary
Mode and activate the control device in the corresponding forward direction to operate the tilt
function. Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
number 1114808, for complete switch option operating instructions.
3. Release four-way toggle switch to neutral position.
NOTE: The four-way toggle switch will alternate functions (increase tilt angle, decrease tilt
angle) after it has been released to the neutral position for a minimum of one (1) second.
NOTE: Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
number 1114808 for complete four-way toggle switch operating instructions.
LED
Single Function
Toggle Switch
FULL UPRIGHT POSITION FULL TILT POSITION
LED
Optional Four-Way
Toggle Switch (Shown
in Neutral Position)
TILT ONLY
