Invacare®SoftformActive®2withRXpump
5.2Controlunitmenudisplay
Overview
E D C B A
Pos.
DescriptionFunction
A
Mutebutton
Therelevantaudible/visibleindicatorturnsonwhenlowpressure,
powerfailureoralternatefailureisrecognised.Tomutetheaudible
signal,presstheMutebutton.Thevisibleindicatorwillashuntilthe
problemissolved.Iftheproblemindicatedhasnotbeensolvedwithin
10minutes,theindicatorwillsoundagain.PresstheMutebuttonto
mutetheaudibleindication,theindicatorwillnotsoundagain.Referto
chapter8Troubleshooting,page15
.
B
Systemincycle/Setupindicator
(OperativeLED)
GreenLEDindicatorasheswhilstsystemissettingup–SolidgreenLED
indicatesnormaloperational.
C
Alternatingsystem/Timingfailure
indicator
RedLEDindicatorashesandaudiblebuzzersoundsifthesystem
recognisesacycletimeproblem.
D
PowerfailureindicatorRedLEDindicatorashesandaudiblebuzzersoundsifthesystemhas
nopowerconnected.Thiscouldbeintheeventofapowerfailure,for
examplecausedbypowercordunpluggedorpoweroffwhencontrol
unitisworking.Whenpowerisrestored,controlunitwillautomatically
startworking.
E
Pressurefailure/Lowpressure
indicator
RedLEDindicatorashesandaudiblebuzzersoundsifthesystem
recognisesalowpressurefailure.
Operation
1.Thepowerindicatorwillashandcontrolunitwillenterstaticmodeinitiallyuntilpressurereaches15mmHg.Thencontrol
unitwillenteralternatemodeandpowerindicatorwillremainon.Thecycletimeissetat10min,andthepressureis
setat60±3mmHg.
Therstinationofnewmattress:theindicatorfunction(visibleandaudibleindicators)willactivateifthemattress
doesnotinatecompletelywithin15minutes.
Operationfailures
•Duringcontrolunitoperation,lowpressureindicatorwillactivatewithin1minutesifairhosesaredisconnectedor
aircellsarebroken.
•Inthecaseofabnormalalternateornoalternate,theaudiblesignalwillbeactivatedandalternatefailureindicator
willash.
5.3CPRprocedure
TheInvacare®SoftformActive®2Rxmattresshasbeenfully
testedtocomplywiththecurrentCPRstandardof5-6
cmcompressiondepth.Thiswasachievedatallstagesof
ination/deation.
A
B
1.HolddownRedCPRbuttonA.
2.PullhoseconnectorrmlyawayfromthecontrolunitB.
3.Switchoffthecontrolunit.
