Invacare Storm4 - Changing the Arm Support Position

44
8.1.4 Changing the arm support position
Requirements:
• 1x Allen key 3 mm
The arm support has 12 possible positions.
• To change the position of the arm support,
loosen the screw (1) and remove it.
• The position of the arm support is adjusted by
selecting a combination of screw holes in the
arm support and the drillholes in the fixing
plate.
• Reposition the screws and tighten.
