11.3.3 Repairing tyre punctures (drive wheel)
Injury hazard! If the wheel has been insufficiently tightened during assembly, it can
become loosened during driving!
• When reassembling the drive wheels, tighten the Allen screws at a torque of 30 Nm!
• Secure all screws using a suitable blocker (e.g. Loctite 243)!
Requirements:
• Allen key – open-ended spanner 6 mm
• Torque wrench
• Repair kit for tyre repair or a new inner tube
• Talcum powder
• Screw blocker Loctite (e.g. Loctite 243)
Removing the wheel
• Block up the vehicle (place wooden blocks under frame).
• Unscrew the screw (1).
• Remove the wheel from the hub.
