Service Manual
3.Remove panel assy
Remove the five screws fixing panel, lift
and pull outward to remove the panel.
screws
panel
assy
Remove the six screws fixing rear plate to
remove the rear plate.
screws
rear
plate
for C4 panel
4.Remove rear plate
36
Maintenance
