Service Manual
Appendix 3: Resistance Value Table of Humidity Sensor
Relative
humidity
Temperature
（℃）
%RH 5
℃
6
℃
7
℃
8
℃
9
℃
10
℃
11
℃
12
℃
13
℃
14
℃
90 5.35 4.92 4.55 4.23 3.95 3.70 3.47 3.25 3.05 2.87
89 5.80 5.33 4.93 4.58 4.27 4.00 3.74 3.51 3.29 3.09
88 6.29 5.77 5.33 4.95 4.62 4.32 4.03 3.78 3.54 3.32
87 6.82 6.25 5.77 5.36 4.99 4.66 4.35 4.08 3.82 3.58
86 7.40 6.78 6.25 5.80 5.40 5.04 4.70 4.40 4.11 3.85
85 8.03 7.35 6.78 6.28 5.84 5.45 5.09 4.75 4.45 4.16
84 8.71 7.97 7.35 6.81 6.33 5.91 5.50 5.14 4.80 4.49
83 9.44 8.65 7.97 7.39 6.87 6.41 5.96 5.56 5.19 4.84
82 10.25 9.39 8.65 8.02 7.46 6.96 6.47 6.03 5.62 5.24
81 11.13 10.19 9.40 8.71 8.10 7.56 7.03 6.54 6.09
5.68
80 12.09 11.07 10.21 9.46 8.80 8.21 7.62 7.08 6.59 6.13
79 13.14 12.03 11.09 10.28 9.57 8.93 8.28 7.70 7.16 6.66
78 14.27 13.07 12.05 11.17 10.40 9.70 8.99 8.35 7.75 7.20
77 15.50 14.20 13.10 12.14 11.30 10.55 9.78 9.07 8.43 7.83
76 16.84 15.43 14.24 13.21 12.30 11.48 10.64 9.87 9.16 8.51
75 18.31 16.78 15.49 14.37 13.38 12.50 11.58 10.75 9.98 9.26
74 19.91 18.25 16.85 15.64 14.57 13.62 12.62 11.72 10.89 10.12
73 21.67 19.87 18.35 17.04 15.88 14.84 13.71 12.67 11.72 10.84
72 23.61 21.66 20.00 18.57 17.31 16.18 14.98 13.90 12.89 11.96
71 25.78 23.64 21.84 20.27 18.89 17.66 16.35 15.16 14.06 13.05
70 28.15 25.82 23.85 22.15 20.65 19.30 17.91 16.63 15.46 14.37
69 30.78 28.24 26.10 24.24 22.60 21.13 19.60 18.19 16.91 15.71
68
33.69 30.92 28.58 26.55 24.76 23.16 21.48 19.94 18.53 17.22
67 36.90 33.88 31.33 29.11 27.16 25.42 23.56 21.86 20.29 18.85
66 40.45 37.16 34.37 31.96 29.84 27.93 25.83 23.92 22.15 20.52
65 44.38 40.78 37.74 35.11 32.78 30.70 28.42 26.34 24.42 22.65
64 48.75 44.81 41.48 38.59 36.05 33.77 31.24 28.93 26.80 24.83
63 53.64 49.31 45.65 42.48 39.68 37.17 34.34 31.74 29.36 27.15
62 59.14 54.36 50.32 46.82 43.73 40.97 37.83 34.96 32.32 29.87
61 65.31 60.02 55.55 51.68 48.26 45.20 41.70 38.51 35.58 32.86
60 72.27 66.40 61.43 57.13 53.33 49.94 46.07 42.53 39.28 36.27
59 80.13 73.58 68.04 63.25 59.01 55.23 50.94 47.03 43.43 40.10
58 88.92 81.61 75.43 70.08 65.36 61.14 56.40 52.08 48.
11 44.43
57 98.86 90.68 83.77 77.78 72.50 67.78 62.49 57.67 53.23 49.12
56 112.59 102.79 94.50 87.33 81.00 75.33 69.42 64.03 59.07 54.48
55 122.69 112.51 103.91 96.45 89.88 84.00 77.42 71.41 65.88 60.76
54 137.09 125.76 116.19 107.89 100.57 94.03 86.69 79.99 73.82 68.11
53 153.46 140.88 130.25 121.03 112.91 105.64 97.26 89.61 82.58 76.06
52 172.19 158.19 146.35 136.10 127.05 118.96 109.52 100.90 92.97 85.63
51 193.69 178.04 164.81 153.36 143.25 134.21 123.35 113.43 104.31 95.86
50 218.48 200.85 185.94 173.02 161.63 151.44 139.14 127.90 117.57 108.01
49 247.23 227.16 210.19 195.49 182.52 170.92 156.84 143.98 132.15 121.20
48 278.74 256.20 237.15 220.64 206.08 193.06 177.34 163.00 149.80 137.58
47 315.50 289.95 268.35 249.64 233.14 218.37 200.56 184.30 169.34 155.49
46 357.93 328.94 304.43 283.20 264.47 247.72 227.57 209.18 192.25 176.59
45 406.44 373.72 346.05 322.08 300.94 282.03 259.22 238.40 219.24 201.51
44 463.66 426.44 394.96 367.70
343.66 322.14 296.25 272.62 250.87 230.74
43 531.25 488.59 452.53 421.28 393.73 369.08 339.44 312.38 287.50 264.45
42 611.22 562.01 520.40 484.35 452.55 424.11 390.24 359.31 330.86 304.52
41 707.78 650.29 601.68 559.58 522.44 489.21 450.38 414.92 382.31 352.11
40 823.98 756.22 698.93 649.30 605.53 566.37 521.46 480.46 442.74 407.81
39 962.72 882.62 814.90 756.23 704.48 658.19 604.79 556.03 511.18 469.66
HIS-06 temperature and humidity characteristic5
℃～
14
℃
Unit:KΩ
50
