INVENTOR EVI-18 Service Manual

3
Specifications
2.
Specifications
2.1 Unit Specifications
EVI18
EVO18
EVI18 EVO18
Rated Voltage V

220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Indoor Indoor
W 5300(1050~6500) 5300(1050~6500)
W / 5700(1000~7000)
W 1650(360~2650) 1600(360~2500)
W - 1578(350~2600)
A 7.65 7.12
A- 7.03
W 2650 2600
A12 11.6
m
3
/h 800/680/560/460/-
800/680/560/460/-
L/h 1.8 1.8
W/W 3.21 3.31
W/W - 3.61
W/W - -
W/W - -
m
2
23-34
23-34
EVI18 EVO24
EVI18 EVO24
Fan Type Cross-flow Cross-flow
Diameter Length(DXL) mm 98X650 98X650
Fan Motor Cooling Speed
(SH/H/ML/SL)
r/min
1300/1100/950/800/-
1300/1100/950/800/-
Fan Motor Heating Speed
(SH/H/ML/SL)
r/min
-
1400/1200/1050/900/-
Output of Fan Motor W 20 20
Fan Motor RLA A 0.31 0.31
Fan Motor Capacitor F 1.5 1.5
Input of Heater W - -
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm 7 7
Row-fin Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 657X25.4X304.8 657X25.4X304.8
Swing Motor Model MP28VB MP28VB
Output of Swing Motor W 2 2
Fuse A PCB 3.15A PCB 3.15A
Sound Pressure Level
(SH/H/M/L/SL)
dB (A)
45/40/37/32/-
45/40/37/32/-
Sound Power Level
(SH/H/M/L/SL)
dB (A)
55/50/47/42/-
55/50/47/42/-
Dimension (WXHXD) mm 865x305x215 865x305x215
Dimension of Carton Box
(L/W/H)
mm
945X380X295
945X380X295
Dimension of Package (L/W/H) mm 948X383X310 948X383X310
Net Weight kg 12 12
Gross Weight kg 16 16
Mode l
Dehumidifying Volume
EER
Model of indoor unit
Power
Supply
Power Supply Mode
Cooling Capacity (Min

Max)
Indoor
Unit
COP
SEER
HSPF
Application Area
Air Flow Volum e(SH/H/M/L/SL)
Cooling Power Current
Heating Power Current
Rated Input
Rated Current
Heating Capacity (Min

Max)
Cooling Power Input (Min

Max)
Heating Power Input (Min

Max)
Models: EVI18, EVI18,EVO24, EVO24

INVENTOR EVI-18 Specifications

General

Brand	INVENTOR
Model	EVI-18
Category	Air Conditioner
Language	English
