Indoor Unit
Outdoor Unit
Remote controller
Outer side of the controller
Inlet
Air Purifying Filter
(inside)
ON/OFF
Button
Inlet grille
(adjust left and
ow)
Vertical blade
right air fl
Horizontal flap
(adjust up and down air flow
Don't adjust it manually)
Outlet
Display board
(inside)
Display board
2
3
Signal receiver hole
1
Ambient temp.display
When receiving the remote
control signal, display the set
temperature.
2
3
Operation mode indicator
(lights up when the compressor is on.)
4
WIFI
4
