INVENTOR V4MRFI-24 - Page 63

Pagina 13 
H
D
W
760x590x285 (29.9x23.2x11.2) 530 (20.85) 290 (11.4)
810x558x310 (31.9x22x12.2) 549 (21.6) 325 (12.8)
845x700x320 (33.27x27.5x12.6) 560 (22) 335 (13.2)
900x860x315 (35.4x33.85x12.4) 590 (23.2) 333 (13.1)
945x810x395 (37.2x31.9x15.55) 640 (25.2) 405 (15.95)
990x965x345 (38.98x38x13.58) 624 (24.58) 366 (14.4)
946x810x420 (37.24x31.9x16.53) 673 (26.5)
403 (15.87)
946x810x410 (37.24x31.9x16.14) 673 (26.5)
403 (15.87)
952x1333x410 (37.5x52.5x16.14) 634 (24.96)
404 (15.9)
952x1333x415 (37.5x52.5x16.34) 634 (24.96)
404 (15.9)
845x702x363 (33.27x27.6x14.3)
540 (21.26)
350 (13.8)
938x1369x392 (36.93x53.9x15.43) 634 (24.96) 404 (15.9)
900x1170x350 (35.4x46x13.8) 590 (23.2) 378 (14.88)
800x554x333 (31.5x21.8x13.1) 514 (20.24) 340 (13.39)
A
B
D
W
H
W
H






Unitate de exterior de tip split
(A se vedea Fig. 5.4, 5.5, 5.6, 5.10
și Tabelul 5.1)





(A se vedea Fig.5.7, 5.8, 5.9 și Tabelul 5.2)
(Perete sau obstacol)
(Perete sau obstacol)
>30cm / 11.8”
>30cm / 11.8”
>30cm /
11.8”
>30cm /
11.8”
Admisie aer
Admisie aer Admisie aer
Admisie aer
Evacuare aer
L
A
L
Dimensiunile unității de
exterior (l x î x d)
Dimensiuni de montare
Distanța B
Y
Distanța A
M Π
ΜΟΝΤΕΛΟ
ΔΙΑΣΤΑΣΕΙΣ
18 633/25 554/21.8554/21.8
24 633/25 554/21.8554/21.8
36 759/29.8 554/21.8554/21.8
36 633/25 600/23.6600/23.6
48 759/29.8 710/28710/28
60 843/33 710/28710/28
MODEL
Dimensiuni
l î d
