Optidrive ODE-3 1Ph Output User Guide Revision 1.00
Quick Start – IP20 & IP66 Non Switched
Connect a Start / Stop switch between control terminals 1 & 2
Close the Switch to Start
Open to Stop
Connect a potentiometer (5k – 10kΩ) between terminals as shown
to vary the speed from P-2 (0Hz default) to P-01 (50 / 60 Hz default)
Quick Start – IP66 Switched
Switch the unit on using the isolator switch on the panel.
The OFF/REV/FWD will enable the output to the motor.
NOTE : With single phase motors, forward rotation only is possible.
The potentiometer will control the speed.
To Next Page
