General Information and Ratings
2. General Information and Ratings
This chapter contains information about the Optidrive E3 including how to identify the drive
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the drive
nameplate. The model number includes the drive and any options.
ODE
-
3
-
1
2
0021
-
1
F
1
2
-01
Single Phase Output
Product Family
IP Rating
2 = IP20
X = IP66 Non Switched
Y = IP66 Switched
Generation
Dynamic Brake
Transistor
1 = Not Fitted
4 = Internal Transistor
Frame Size
Filter Type
0 = No Filter
F = Internal EMC Filter
Input Voltage
1 = 110 – 115
2 = 200 – 240
No. Of Input Phases
Output Current x 10
2.2. Drive Model Numbers
110 – 115V + / - 10% - 1Phase Input – 1 Phase 110V Output (Voltage Doubler)
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
N/A
ODE-3-110070-101#-01
0.5
7.0
1
N/A
ODE-3-210105-104#-01
0.75
10.5
2
200 – 240V + / - 10% - 1Phase Input – 1 Phase Output
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
ODE-3-120043-1F1#-01
ODE-3-120043-101#-01
0.37
0.5
4.3
1
ODE-3-120070-1F1#-01
ODE-3-120070-101#-01
0.75
1
7.0
1
ODE-3-120105-1F4#-01
ODE-3-120105-104#-01
1.1
1.5
10.5
2
NOTE
For IP20 units, replace ‘#’ with ‘2’
For IP66 Non Switched Units, replace ‘#’ with ‘X’
For IP66 Switched Units, replace ‘#’ with ‘Y’
