Parameters
6.4. P-00 Read Only Status Parameters
Description
Display range
Explanation

1st Analog input value
0 … 100%
100% = max input voltage

2nd Analog input value
0 … 100%
100% = max input voltage

Speed reference input
-P-01 … P-01
Displayed in Hz if P-10 = 0, otherwise displayed in RPM

Digital input status
Binary value
Drive digital input status

Internal Temperature
-10 - 50ᵒC
Displays the internal drive temperature

DC Bus Ripple
0 – 150V
Displays the level of voltage ripple present on the DC Bus, used
for phase loss and imbalance monitoring

Applied motor voltage
0 … 600V AC
Value of RMS voltage applied to motor

DC bus voltage
0 … 1000V dc
Internal DC bus voltage

Internal Heatsink temperature
-20 … 100 °C
Temperature of heatsink in
°
C

Hours run meter
0 to 99 999 hours
Not affected by resetting factory default parameters

Run time since last trip (1)
0 to 99 999 hours
Run-time clock stopped by drive disable (or trip), reset on next
enable only if a trip occurred. Reset also on next enable after a
drive power down.

Run time since last trip (2)
0 to 99 999 hours
Run-time clock stopped by drive disable (or trip), reset on next
enable only if a trip occurred (under-volts not considered a trip)
– not reset by power down / power up cycling unless a trip
occurred prior to power down

Run time since last disable
0 to 99 999 hours
Run-time clock stopped on drive disable, value reset on next
enable

Drive Effective Switching
Frequency
4 to 32 kHz
Actual drive effective output switching frequency. This value
maybe lower than the selected frequency in P-17 if the drive is
too hot. The drive will automatically reduce the switching
frequency to prevent an over temperature trip and maintain
operation.

DC bus voltage log
0 … 1000V
8 most recent values prior to trip, updated every 250ms

Thermistor temperature log
-20 … 120 °C
8 most recent values prior to trip, updated every 500ms

Motor current
0 to 2x rated
current
8 most recent values prior to trip, updated every 250ms

Software ID, IO & motor ctrl
e.g. “1.00”, “47AE”
Version number and checksum.
“1” on LH side indicates I/O processor,
“2“ indicates motor control

Drive serial number
000000 … 999999
00-000 … 99-999
Unique drive serial number
e.g. 540102 / 32 / 005

Drive identifier
Drive rating
Drive rating, drive type
e.g. 0.37, 1 230,3P-out
Parameter group zero access and navigation
When P-14 = P-37, all P-00 parameters are visible. Default value is 101.
When the user scrolls to P-00, pressing will display “XX”, where XX represents the secondary number within P-00. (i.e. 1 to 20). The
User can then scroll to the required P-00 parameter.
Pressing once more will then display the value of that particular group zero parameter.
For those parameters which have multiple values (e.g. software ID), pressing the and keys will display the different values within that
parameter.
Pressing returns to the next level up. If is then pressed again (without pressing or ), the display changes to the next level up
(main parameter level, i.e. P-00).
If or is pressed whilst on the lower level (e.g. P00-05) to change the P-00 index, pressing <NAVIGATE> quickly displays that parameter
value.
