involight TRINITY200LED - Part 4: DMX-Assignment

33
-
The "TRINITY200LED occupies 25 or 30 DMX channels and can thus be flexibly controlled and programmed.
NOTE: Basic knowledge of the DMX512 control standard is required so that the device can be operated and
programmed correctly with a DMX controller
MODE/CHANNEL
FUNCTION
VALUE
DESCRIPTION
DMX
Mode
25CH
DMX
Mode
30CH
1
1
PAN
0-255
PAN rotation
2
2
PAN Fine
0-255
PAN Fine rotation
3
3
TILT
0-255
TILT rotation
4
4
TILT Fine
0-255
TILT Fine-rotation
5
5
Pan/Tilt Speed
0-255
PAN/TILT Speed
6
6
Dimmer
0-255
Dimmer 0-100%
7
Dimmer Fine
0-255
Dimmer fine
7
8
Strobe
0-3
Shutter closed
4-103
Strobe Effect, Speed increasing
104-107
No Strobe Effect (Shutter open)
108-207
Opening pulsation, increasing speed
208-212
No Strobe Effect (Shutter open)
213-251
Strobe effect in random mode, speed increasing
252-255
No Strobe effect (Shutter open)
8
9
Cyan
0-255
Cyan 0-100%
9
10
Magenta
0-255
Magenta 0-100%
10
11
Yellow
0-255
Yellow 0-100%
11
12
Color1
0-255
Color1 0-100%
12
13
Color2
0-255
Color2 0-100%
13
14
Color3
0-255
Color3 0-100%
14
15
Static Gobos
wheel
0-9
Open
10-19
Gobo 1
20-29
Gobo 2
30-39
Gobo 3
40-49
Gobo 4
