36
Rotation gobos:
Outer diameter: 22,8 mm +0/-0,2 mm
Max. motive diameter: 19,5 mm
Max. thickness: 4 mm
Gobo switch:
1. Unplug the device from all poles and let it cool down.
2. Remove both head covers. Position the head so that the front lens faces down.
3. Turn the desired gobo wheel until the gobo to be replaced is at the top.
4. Grasp the gobo holder (3) by its teeth, lift it slightly off the gobo wheel and
pull out the holder. ATTENTION: For glass gobos, do not touch the glass with your fingers!
