INVT BD5KTL-RL1 User Manual

Setting Setting
8.2.3 Grid standard
8.2.4 RUN SETTING
Interface Description
--RUN SETTING--
→ 1:REACT MODE
2:GRID POWER
3:DISC P OWER
4:VAC-MIN
5:VAC-MAX
6:FAC-MIN
7:FAC-MAX
Press Up/Down button to move corresponding
corresponding options;
Press Enter to enter the selected menu;
Press ESC button to return to
setting interface.
① Reactive mode
Power factor setting
Reactive Power
Interface
Description
-POWER FACTOR-
INPUT: C1.00
Value range
(L1.00~C1.00)
Press Up/Down to increase or decrease the
input
figure;
Press Enter button to confirm or Esc button
to
cancel the input and return to working
interface;
The input value should range
between L0.80 and L0.99 or C0.8
and C1.00.
Interface
Description
-REA CT POWER-
INPUT: +60%
Press Up/Down button to adjust the input
figure.
Press Emter button to confirm or Esc button
to cancel the input and return to working
interface;
Value range
(-60%~+60%)
The input value should range between -60%
and
+60%, which varies with the standard.
Interface
Description
--GRID STD--
→ 1:220V/50HZ
2:230V/50HZ
3:240V/50HZ
4:220V/60HZ
5:230V/60HZ
6:240V/60HZ
Press Up/Down button to move
corresponding options;
Press the Enter key to confirm the
selection.
Press ESC button to cancel the selection
and
and return to setting interface (refer to
8.2).
Interface
Description
--REACT MODE--
→ 1: POWER FACTOR
2: REACT POWER
3:QU WAVE
4:QP WAVE
Press Up/Down button to move corresponding
options;
Press Enter to confirm the input and enter
power factor setting interface; (select 2,
press Enter to confirm input and enter
reactive power interface; Select 3, 4,the
corresponding mode will be selected and
return to the parameter setting interface.)
Press Esc button to cancel the input and
return
to operation parameters interface.
56 57
