INVT BD5KTL-RL1 User Manual

Setting Setting
② Grid-connected power
Interface
Description
-GRID PERCENT-
INPUT: 100%
Value range
(0~100)
Press Up/Down button to adjust the input
figure;
Press Enter button to confirm or Esc
button to cancel the input and return to
operation parameters interface;
The input value should range between 0 and
100.
③ Discharge power
Interface
Description
-DISC PERCENT-
INPUT: 050%
Value range
(0~100)
Press Up/Down button to adjust the input
figure;
Press Enter button to confirm or Esc
button to cancel the input and return to
operation interface;
The input value should range between 0 and
100.
④ VAC-MIN
Interface
Description
-GRID VOLT LOW-
INPUT: UNIT: V
Value range
(176~270V)
Grid Low Voltage Protection Point .
Press Up/Down to adjust the input
figure; Press Enter to confirm the
input.
Press ESC button to cancel the input and
return to operation parameters interface;
The value should range between 176V and
270,
which varies with different standards.
⑤ VAC-MAX
⑥ FAC-MIN
Interface
Description
-GRID VOLT
HIGH- INPUT:
UNIT: V
Value range
(240~280V)
Grid Over Voltage Protection Point.
Press Up/Down to adjust the input
figure; Press Enter to confirm the
input.
Press Esc to cancel the input and
return to operation parameters interface;
The value should range between 240V and 280V,
which varies with different standards.
⑦ FAC-MAX
Interface
Description
-GRID FREQ
LOW- INPUT:
Grid Low Frequency Protection Point
Press Up/Down to adjust the input figure;
UNIT: Hz
Press Enter to confirm the input.
Press Esc to cancel the input and return to
operation parameters interface;
Value range
(45~49.8)
The value ranges between 45 and 49.8,which
varies with different standards.
Interface
Description
-GRID FREQ HIGH-
INPUT: 52.0
UNIT: Hz
Value range
(50.2~55V)
Grid Over Frequency Protection Point.
Press Up/Down to adjust the input
number; Press Enter to confirm the
input.
Press ESC to cancel the input and
return to operational parameters
interface;
The value ranges between 50.2 and 55, which
varies with different standards.
58 59
