INVT CHV Series User Manual

List of Function Parameters
120
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P7.05
Keypad display
selection
0: Preferential to external
keypad
1: Both display, only external
key valid.
2: Both display, only local
key valid.
3: Both display and key valid.
0 ○
KEYPAD
DISPLAY
P7.06
Running status
display selection
1.Output frequency
2.Reference frequency
3.DC bus voltage
4.Output voltage
5.Output current
Other parameters display is
determined by 16 bit binary
digit
BIT0: Rotation speed
BIT1: Output power
BIT2: Output torque
BIT3: PID preset
BIT4: PID feedback
BIT5: Input terminal status
BIT6: Output terminal status
BIT7: AI1
BIT8: AI2
BIT9: AI3
BIT10: AI4
BIT11: HDI1
BIT12: HDI2
BIT13: Step No. of PLC
BIT14: Length value
BIT15: Count value
0x00FF ○
RUNNING
DISPLAY
P7.07
Stop status display
selection
BIT0: Reference frequency
BIT1: DC bus voltage
BIT2: Input terminal status
BIT3: Output terminal status
BIT4: PID preset
BIT5: PID feedback
BIT6: AI1
BIT7: AI2
BIT8: AI3
BIT9: AI4
BIT10: HDI1
BIT11: HDI2
BIT12: Step No. of PLC
BIT13: Length value
BIT14: Reserved
BIT15: Reserved
0x00FF ○
STOP
DISPLAY
