INVT CHV Series User Manual

List of Function parameters
125
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P9.04
Proportional gain
(Kp)
0.00~100.00 0.10 ○
PROPORTIO
N GAIN
P9.05 Integral time (Ti) 0.01~10.00s 0.10s ○
INTEGRAL
TIME
P9.06
Differential time
(Td)
0.00~10.00s 0.00s ○
DIFFERENTI
A TIME
P9.07 Sampling cycle (T) 0.01~100.00s 0.50s ○
SAMPLING
CYCLE
P9.08 Bias limit 0.0~100.0% 0.0% ○ BIAS LIMIT
P9.09
PID output filter
time
0.00~10.00s 0.00 ○
OUTPUT
FILTER
P9.10
Feedback lost
detecting value
0.0~100.0% 0.0% ○
FEEDBACK
LOST
P9.11
Feedback lost
detecting time
0.0~3600.0s 1.0s ○
FEEDBACK
LOST(t)
PA Group: Multi-step Speed Control
PA.00 Simple PLC mode
0: Stop after one cycle
1: Hold last frequency after
one cycle
2: Circular run
0 ○ PLC MODE
PA.01
Simple PLC status
saving selection
0: Not saved
1: Saved
2: Not saved when power off,
saved when stop
0 ○
STATUS
SAVING
PA.02 Multi-step speed 0 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 0
PA.03
0
th
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 0
PA.04 Multi-step speed 1 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 1
PA.05
1
st
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 1
PA.06 Multi-step speed 2 -100.0~100.0% 0.0% ○
MULTI-SPEE
D 2
PA.07
2
nd
Step running
time
0.0~6553.5s(h) 0.0s ○
RUNNING
TIME 2
