Detailed Function Description
73
Setting
Value
Function Range
0 Running frequency 0~maximum frequency (P0.07)
1 Reference frequency 0~ maximum frequency (P0.07)
2 Motor speed 0~2* rated synchronous speed of motor
3 Output current 0~2* inverter rated current
4 Output voltage 0~2* inverter rated voltage
5 Output power 0~2* rated power
6 Output torque 0~2*rated torque
7 AI1 voltage 0~10V
8 AI2 voltage/current 0~10V/0~20mA
9 AI3 voltage -10V~10V
10 AI4 voltage 0~10V
11 HDI1 frequency 0.1~50.0kHz
12 HDI2 frequency 0.1~50.0kHz
13 Length value 0~preset length (P8.19)
14 Count value 0~preset count value (P8.22)
Function
Code
Name Description
Setting
Range
Factory
Setting
P6.10 AO1 lower limit 0.0%~100.0% 0.0~100.0 0.0%
P6.11
AO1 lower limit
corresponding output
0.00V ~10.00V 0.00~10.00 0.00V
P6.12 AO1 upper limit 0.0%~100.0% 0.0~100.0 100.0%
P6.13
AO1 upper limit
corresponding output
0.00V ~10.00V 0.00~10.00 10.00V
P6.14 AO2 lower limit 0.0%~100.0% 0.0~100.0 0.0%
P6.15
AO2 lower limit
corresponding output
0.00V ~10.00V 0.00~10.00 0.00V
P6.16 AO2 upper limit 0.0%~100.0% 0.0~100.0 100.0%
P6.17
AO2 upper limit
corresponding output
0.00V ~10.00V 0.00~10.00 10.00V
