(3) Power distribution module installation
Install the module at the side of charger, then insert the current transfer to power input wire L（L1,L2,L3 for three phase）
5.2 General Specification
1. Engineer / user shall provide 4 expansion bolts of M6x50mm and support 10kg.
2. See the detailed Charger requirement of installation space as follows:
Specific technical data:
Recommended Specification (mm)
Note: The range of installation size can be selected according to local regulatory requirements or actual installation
conditions of the location.
