INVT EVC16 Series User Manual

10
D
Output characteristics
J
Manufacturer LOGO
E
Protection degree
K
Company name
F
Implementation standards
-
-
Note: The data in the figure is only a reference and does not represent the physical nameplate of the product. To view
the applicable data, find the nameplate on the charger.
2.2 Product technical parameters
Electrical parameters
Model
EVC16-AW7KGP1UE
EVC16-AW11KGP1UE
EVC16-AW22KGP1UE
Comment
Input
parameters
Input
mode
Single-phase
three-wire
Three-phase five-wire
Note: The
product is
suitable for T-N
system.
Voltage
range
230Vac±10%
400Vac±10%
Note: The
product works
normally within
this voltage
range.
Frequency
range
45～65 Hz
-
Rated
frequency
50/60 Hz
-
Rated
voltage
230Vac
400Vac
-
Rated
current
≤32A
≤16A
≤32A
-
Output
parameters
Rated
voltage
230Vac
400Vac
Note: The output
voltage varies
with the input
voltage.
Rated
current
≤32A
≤16A
≤32A
-
Rated
power
7 kW
11 kW
22 kW
-
Power factor
≥0.99
Rating condition
Efficiency
≥99.5％
Rating condition
Standby power consumption
≤5 W
Rating condition
Current measurement range
10mA~50A;±0.5%
10mA~25A;±0.5%
10mA~50A;±0.5%
-
Accuracy class
Level 1.0
-
Input protection type
Type A RCD;≤30mA
-
Protective function
Leakage current protection; Over current protection; Short circuit
protection; Detection gun disconnection protection; Grounding protection,
Note: Lightning
protection for its
