Appendix B Dimension drawings
This chapter describes the dimension drawings of Goodrive350 series VFDs. The
dimension unit used in the drawings is mm.
B.1 Keypad structure
9.5
7
56
32
17
8.4
42
7
18.2
18.9
34.3
62
6.5
15.3
15
13.9
75
Figure B-1 Keypad structure diagram
42.0
5.2
62.0
19.0
17.1
48.1
19.0
16.0
26.0
8.0
2-Ø4.5
Figure B-2 Hole-cutting diagram for non-bracket keypad
If the keypad is externally installed on an optional keypad adapter bracket, it can be 20
meters away from the VFD at most.
