INVT GD10-0R4G-S2-B User Manual

Goodrive10 Series Mini VFD Function parameters
-56-
Function
code
Name
Description
Default
Modify
P07.56
Output
terminal state
of the 2nd-last
fault
0
●
P08 group Enhanced functions
Function
code
Name
Description
Default
Modify
P08.00
ACC time 2
Refer to P00.11 and P00.12 for detailed
definition.
Goodrive10 series define four groups of
ACC/DEC time which can be selected by P5
group. The first group of ACC/DEC time is the
factory default one.
Setting range:0.0–3600.0s
Depend
on
model
○
P08.01
DEC time 2
Depend
on
model
○
P08.06
Running
frequency of
jogging
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.0
0Hz–P00.03 (max. output frequency)
5.00Hz
○
P08.07
ACC time of
jogging
Jogging ACC time means the time needed for
the VFD to accelerate from 0Hz to the max.
output frequency (P00.03).
Jogging DEC time means the time needed for
the VFD to decelerate from the max. output
frequency (P00.03) to 0Hz.
Setting range:0.0–3600.0s
Depend
on
model
○
P08.08
DEC time of
jogging
Depend
on
model
○
P08.15
Traverse
range
This function applies to the industries where
traverse and convolution function are required
such as textile and chemical fiber.
The traverse function means that the output
frequency of the VFD is fluctuated with the set
frequency as its center. The route of the
running frequency is illustrated as below, of
which the traverse is set by P08.15 and when
P08.15 is set as 0, the traverse is 0 with no
function.
0.0%
○
P08.16
Sudden
jumping
frequency
range
0.0%
○
P08.17
Traverse
boost time
5.0s
○
P08.18
Traverse
declining time
5.0s
○
