INVT GD100-5R5G-4-PV

Goodrive100-PV Series Solar Pumping VFD Function parameters
54
Function
code
Name
Detailed illustration of parameters
Default
Modify
set by P15.24. To prevent frequent
switching, this threshold must be
greater than P15.33.
If the value is 0.0, it is invalid.
The default value depends on model.
P15.35
Rated pump flow
The pump flow is
Q
N
if the pump
runs at the rated pump frequency and
rated lift. Unit: cubic meter/hour.
0.0
○
P15.36
Rated pump lift
The pump lift is
N
H
if the pump runs
at the rated frequency and rated
current. Unit: meter
0.0
○
P15.37
Voltage setting at
PV undervoltage
point
When the PV voltage is less than the
preset voltage, the system reports the
PV undervoltage (UV) fault.
The default value depends on the
model.
Model
PV UV
point
-SS2
140V
-S2
140V
-2
140V
-4
240V
Any model with
the boost module
70V
Setting range: 0.0–400.0
70.0
○
P15.39
Model
This function code is provided for users
to change models. For example, if the
user wants to use model -4 (default after
0
◎
