INVT GD300-2R2G-4

Goodrive300 Series VFD Basic operation instruction
175
Function
code
Name
Detailed instruction of parameters
Default
value
P10.23
Running time of step 10
0.0–6553.5s (min)
0.0s
P10.24
Multi-step speed 11
-100.0–100.0%
0.0%
P10.25
Running time of step 11
0.0–6553.5s (min)
0.0s
P10.26
Multi-step speed 12
-100.0–100.0%
0.0%
P10.27
Running time of step 12
0.0–6553.5s (min)
0.0s
P10.28
Multi-step speed 13
-100.0–100.0%
0.0%
P10.29
Running time of step 13
0.0–6553.5s (min)
0.0s
P10.30
Multi-step speed 14
-100.0–100.0%
0.0%
P10.31
Running time of step 14
0.0–6553.5s (min)
0.0s
P10.32
Multi-step speed 15
-100.0–100.0%
0.0%
P10.33
Running time of step 15
0.0–6553.5s (min)
0.0s
P10.36
PLC restart
0: Restart from the first stage
1:Continue to run from the stop
frequency
0
P10.34
Simple PLC 0–7 step
ACC/DEC time
0x0000–0XFFFF
0000
P10.35
Simple PLC 8–15 step
ACC/DEC time
0x0000–0XFFFF
0000
P05.01–
P05.09
Digital input function
selection
23:Simple PLC stop reset
24:Simple PLC pause
P06.01–
P06.04
Digital outnput function
selection
15: Underload pre-alarm
16:Completion of simple PLC stage
P17.00
Setting frequency
0.00Hz–P00.03
(Max. output frequency)
0.00Hz
P17.27
Simple PLC and the
current stage of the
multi-step speed
0–15
7.14 Multi-step speed running
Set the parameters when the VFD carries out multi-step speed running. Goodrive300 series VFDs
can set 16 stage speed which can be selected by the combination code of multi-step speed terminals
1–4. They correspond to multi-step speed 0 to 15.
