Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure
15
Serial
No.
Name
Description
1
State
LED
RUN/TUNE
LED off means that the VFD is in the
stopping state; LED blinking means the
VFD is in the parameter autotune state;
LED on means the VFD is in the running
state.
FWD/REV
FED/REV LED
LED off means the VFD is in the forward
rotation state; LED on means the VFD is
in the reverse rotation state.
LOCAL/REMOT
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the VFD is in the
keypad operation state; LED blinking
means the VFD is in the terminals
operation state; LED on means the VFD
is in the remote communication control
state.
TRIP
LED for faults
LED on when the VFD is in the fault state;
LED off in normal state; LED blinking
means the VFD is in the pre-alarm state.
2
Unit
LED
Mean the unit displayed currently
Hz
Frequency unit
RPM
Rotating speed unit
A
Current unit
％
Percentage
V
Voltage unit
3
Display
zone
5-figure LED display displays various monitoring data and alarm code such
as set frequency and output frequency.
