Goodrive100-PV Series Solar Pumping VFD Function parameters
24
Detailed illustration of parameters
Upper limit of the
running frequency
The upper limit of the running frequency is
the upper limit of the output frequency of
the VFD which is lower than or equal to
the maximum frequency.
Setting range: P00.05–P00.03 (Max.
output frequency)
Lower limit of the
running frequency
The lower limit of the running frequency is
that of the output frequency of the VFD.
The VFD runs at the lower limit frequency
if the set frequency is lower than the lower
limit.
Note: Max. output frequency ≥ Upper limit
frequency ≥ Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper
limit of the running frequency)
ACC time means the time needed if the
VFD speeds up from 0Hz to the Max.
output frequency (P00.03).
DEC time means the time needed if the
VFD speeds down from the Max. output
frequency to 0Hz (P00.03).
GD100-PV series VFDs have four groups
of ACC/DEC time which can be selected
by P05. The factory default ACC/DEC
time of the VFD is the first group.
Setting range of P00.11 and P00.12: 0.0–
3600.0s
0: Runs at the default direction. The VFD
