Goodrive20-EU series VFD Function parameters
64
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.51
Corresponding
setting of HDI
low frequency
setting
-100.0% – 100.0%
0.0%
○
P05.52
Upper limit
frequency of
HDI
P05.50 – 50.000kHz
50.000
kHz
○
P05.53
Corresponding
setting of upper
limit frequency
of HDI
-100.0% – 100.0%
100.0%
○
P05.54
HDI frequency
input filter time
0.000s – 10.000s
0.100s
○
P06 Group Output terminals
P06.01
Y1 output
selection
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency level test FDT1
7: Frequency level test FDT2
8: Frequency reached
9: Zero speed running
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
27
P06.03
Relay RO1
output
selection
1
○
P06.04
Relay RO2
output
selection
5
○
