Goodrive20-EU series VFD Function parameters
91
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P10.37
Multi-step time
unit selection
0: Seconds; the running time of all stages is
counted by second
1: Minutes; the running time of all stages is
counted by minute
0
◎
P11 Group Protective parameters
P11.00
Phase loss
protection
0x00 – 0x11
LED ones:
0: Input phase loss software protection disable
1: Input phase loss software protection enable
LED tens:
0: Output phase loss protection disable
1: Output phase loss protection enable
LED hundreds:
0: Input phase loss hardware protection disable
1: Input phase loss hardware protection enable
0x10
○
P11.01
Frequency-
drop at sudden
power dip
0: Disable
1: Enable
0
○
P11.02
Frequency-
drop ratio at
sudden power
dip
Setting range: 0.00Hz/s – P00.03 (the max.
frequency)
After the power loss of the grid, the bus voltage
drops to the sudden frequency-decreasing point,
the VFD begin to decrease the running
frequency at P11.02, to make the VFD generate
power again. The returning power can maintain
the bus voltage to ensure a rated running of the
VFD until the recovery of power.
Voltage
degree
220/
230V
400V
460V
660V
Frequency
decrease
point at
sudden
power loss
260V
460V
530V
800V
Note: 1. Adjust the parameter properly to avoid
the stopping caused by VFD protection during
the switching of the grid.
10.00
Hz/s
○
