INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-30-
Function
code
Name
Parameter description
Default
value
Modify
and P21.04, P21.05, P21.06 in P21 group will
stay in present value.
P01.01
Starting frequency of
direct startup
0.00–50.00Hz
0.50Hz
◎
P01.08
Stop mode selection
0: Decelerate to stop
1: Coast to stop
0
○
P01.15
Stop speed
0.00–100.00Hz
0.50Hz
◎
P01.16
Stop speed detection
mode
0: Detect as per the set speed value (judge
the ramps frequency)
1: Detect as per the speed feedback value
(valid for vector control only)
1
◎
P01.17
Feedback speed
detection time
0.00–100.00 s (valid only when P01.16=1)
0.50s
◎
P02.00
Type of motor 1
0: Asynchronous motor
1: Synchronous motor
0
◎
P02.01
Rated power of
asynchronous motor 1
0.1–3000.0kW
Depend
on model
◎
P02.02
Rated frequency of
asynchronous motor 1
0.01Hz–P00.03 (max. frequency)
50.00Hz
◎
P02.03
Rated speed of
asynchronous motor 1
1–36000rpm
Depend
on model
◎
P02.04
Rated voltage of
asynchronous motor 1
0–1200V
Depend
on model
◎
P02.05
Rated current of
asynchronous motor 1
0.8–6000.0A
Depend
on model
◎
P02.06
Stator resistor of
asynchronous motor 1
0.001–65.535Ω
Depend
on model
○
P02.07
Rotor resistor of
asynchronous motor 1
0.001–65.535Ω
Depend
on model
○
P02.08
Leakage inductance of
asynchronous motor 1
0.1–6553.5mH
Depend
on model
○
P02.09
Mutual inductance of
asynchronous motor 1
0.1–6553.5mH
Depend
on model
○
P02.10
No-load current of
asynchronous motor 1
0.1–6553.5A
Depend
on model
○
P02.11
Saturation coefficient 1
of the iron core of
asynchronous motor 1
0.0–100.0%
80.0%
◎
P02.12
Saturation coefficient 2
0.0–100.0%
68.0%
◎
