INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-31-
Function
code
Name
Parameter description
Default
value
Modify
of the iron core of
asynchronous motor 1
P02.13
Saturation coefficient 3
of the iron core of
asynchronous motor 1
0.0–100.0%
57.0%
◎
P02.14
Saturation coefficient 4
of the iron core of
asynchronous motor 1
0.0–100.0%
40.0%
◎
P02.15
Rated power of
synchronous motor 1
0.1–3000.0kW
Depend
on model
◎
P02.16
Rated frequency of
synchronous motor 1
0.01Hz–P00.03 (max. frequency)
50.00Hz
◎
P02.17
Pole pairs of
synchronous motor 1
1–50
2
◎
P02.18
Rated voltage of
synchronous motor 1
0–1200V
Depend
on model
◎
P02.19
Rated current of
synchronous motor 1
0.8–6000.0A
Depend
on model
◎
P02.20
Stator resistor of
synchronous motor 1
0.001–65.535Ω
Depend
on model
○
P02.21
Direct-axis inductance
of synchronous motor 1
0.01–655.35mH
Depend
on model
○
P02.22
Quadrature-axis
inductance of
synchronous motor 1
0.01–655.35mH
Depend
on model
○
P02.23
Counter-emf constant
of synchronous motor 1
0–10000
350
○
P02.26
Overload protection
selection of motor 1
0: No protection
1: Normal motor (with low speed
compensation)
2: Frequency-conversion motor (without low
speed compensation)
2
◎
P02.27
Overload protection
coefficient of motor 1
Motor overload multiple M = Iout/(In*K)
In is rated motor current, Iout is VFD output
current, K is motor overload protection
coefficient.
The smaller the K is, the larger the value of M
is; the smaller the value of M is, the easier the
protection is.
100.0%
○
