INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Function parameters
111
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P12.13
Magnetic
saturation
coefficient 3
for the iron
core of AM2
0.0–100.0%
57.0%
◎
P12.14
Magnetic
saturation
coefficient 4
for the iron
core of AM2
0.0–100.0%
40.0%
◎
P12.15
Rated power
of
synchronous
motor 2
0.1–3000.0kW
Set the parameter of the
controlled asynchronous
motor.
In order to ensure the
controlling performance, set
the P12.151–P12.19
according to the name plate of
the asynchronous motor.
Goodrive300 series VFDs
provide the function of
parameter autotuning. Correct
parameter autotuning comes
from the correct setting of the
motor name plate.
In order to ensure the
controlling performance,
please configure the motor
according to the standard
principles, if the gap between
the motor and the standard
one is huge, the features of
the VFD will decrease.
Note: Reset the rated power
of the motor (P12.15),
initialize the motor parameter
of P12.16– P12.19.
Depend
on
model
◎
P12.16
Rated
frequency of
synchronous
motor 2
0.01Hz–P00.03
(Max. frequency)
50.00
Hz
◎
P12.17
Number of
poles pairs for
synchronous
motor 2
1–50
2
◎
P12.18
Rated voltage
of
synchronous
motor 2
0–1200V
Depend
on
model
◎
P12.19
Rated current
of
synchronous
motor 2
0.8–6000.0A
Depend
on
model
◎
P12.20
Stator resistor
of
synchronous
motor 2
0.001–65.535Ω
Depend
on
model
○
P12.21
Direct axis
inductance of
0.01–655.35mH
After finish the motor
parameter autotuning, the set
Depend
on
○
