INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
131
Function
code
Name
Detailed instruction of parameters
Default
value
P03.07
Compensation coefficient
of electromotion slip in
vector control
50%–200%
100%
P03.08
Compensation coefficient
of braking slip in vector
control
50%–200%
100%
P03.09
Current loop proportional
coefficient P
0–65535
1000
P03.10
Current loop integral
coefficient I
0–65535
1000
P03.11
Torque setting method
This parameter is used to enable the
torque control mode, and set the torque.
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS/CANopen communication
setting torque
9: Ethernet communication setting torque
10: Reserved
Note: For setting modes of 2–10, 100%
corresponds to three times of the rated
current of the motor.
0
P03.12
Keypad setting torque
-300.0%–300.0%
(rated current of the motor)
50.0%
P03.13
Torque reference filter
time
0.000–10.000s
0.010s
P03.14
Upper frequency of
forward rotation in torque
control
0: Keypad (P03.16 sets P03.14, P03.17
sets P03.15)
1: AI1
2: AI2
3: AI3
0
P03.15
Upper frequency of
reverse rotation in torque
control
0
