INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
132
Function
code
Name
Detailed instruction of parameters
Default
value
4: Pulse frequency HDI
5: Multi-step
6: Modbus communication
7: PROFIBUS/CANopen communication
8: Ethernet communication
9: Reserved
Note: For setting modes of 1–9, 100%
corresponds to the maximum frequency.
P03.16
Keypad setting for upper
frequency of forward
rotation in torque control
Setting range: 0.00Hz–P00.03
(Max. output frequency)
50.00Hz
P03.17
Keypad setting for upper
frequency of reverse
rotation in torque control
50.00Hz
P03.18
Upper electromotion
torque limit setting
source
0: Keypad (P03.20 sets P03.18, P03.21
sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5: Modbus communication
6: PROFIBUS/CANopen communication
7: Ethernet communication
8: Reserved
Note: For setting modes of 1–8, 100%
corresponds tothree times of the motor
current.
0
P03.19
Upper braking torque limit
setting source
0
P03.20
Keypad setting of
electromotion torque
0.0–300.0% (rated current of the motor)
180.0%
P03.21
Keypad setting of braking
torque
180.0%
P03.22
Weakening coefficient in
constant power zone
0.1–2.0
0.3
P03.23
Lowest weakening point in
constant power zone
10%–100%
20%
