INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
136
When the user selects the user-defined V/F curve function in Goodrive300 series VFDs, they can set
the given channel of voltage and frequency and the corresponding ACC/DEC time, or the two can
combinate to form a real-time curve.
Note: the application of V/F curve separation can be used in many cases with various kinds of power
supply of the VFD. But the users should set and adjust the parameters with caution. Incorrect
parameters may cause damage to the VFD.
Function
code
Name
Description
Default
value
P00.00
Speed control mode
0: Sensorless vector control mode 0
(applicable to AM and SM)
1: Sensorless vector control mode 1
(applicable to AM)
2: SVPWM control mode (applicable to
AM and SM)
1
P00.03
Max. output frequency
P00.04–400.00Hz
50.00Hz
P00.04
Upper limit of the running
frequency
P00.05–P00.03
50.00Hz
P00.05
Lower limit of the running
frequency
0.00Hz–P00.04
0.00Hz
P00.11
ACC time 1
0.0–3600.0s
Depend
on model
P00.12
DEC time 1
0.0–3600.0s
Depend
on model
P02.00
Type of motor 1
0: Asynchronous motor
1: Synchronous motor
0
P02.02
Rated frequency of
asynchronous motor 1
0.01Hz–P00.03 (Max. output frequency)
50.00Hz
P02.04
Rated voltage of
asynchronous motor 1
0–1200V
Depend
on model
P04.00
Motor 1 V/F curve setting
0: Straight line V/F curve
1: Multi-dots V/F curve
2: 1.3
th
power low torque V/F curve
3: 1.7
th
power low torque V/F curve
4: 2.0
th
power low torque V/F curve
5: Customized V/F (V/F separation)
0
P04.01
Torque boost of motor 1
0.0%: (automatic) 0.1%–10.0%
0.0%
P04.02
Torque boost close of
motor 1
0.0%–50.0% (rated frequency of motor 1)
20.0%
P04.03
V/F
0.00Hz–P04.05
0.00Hz
