INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Product overview
10
Function
Specification
Synchronous motor: 2.5 Hz/150% (SVC)
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, pulse frequency setting,
multi-step speed running setting, simple PLC setting,
PID setting, Modbus communication setting,
PROFIBUS communication setting.
Switch between the combination and single setting
channel.
Auto-adjustment of the
voltage
Keep constant voltage automatically when the grid
voltage transients
Fault protection
Provide more than 30 fault protection functions:
overcurrent, overvoltage, undervoltage, overheating,
phase loss and overload, etc.
Restart after rotating
speed tracking
Smooth starting of the rotating motor
Peripheral
interface
Terminal analog input
resolution
≤ 20mV
Terminal switch input
resolution
≤ 2ms
Analog input
2 (AI1, AI2) 0–10V/0–20mA and 1 (AI3) -10–10V
Analog output
2 (AO1, AO2) 0–10V /0–20mA
Digital input
8 common inputs, the Max. frequency: 1kHz, internal
impedance: 3.3kΩ;
1 high speed input, the Max. frequency: 50kHz
Digital output
1 high speed pulse output, the Max. frequency: 50kHz;
1 Y terminal open collector output
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Others
Mountable method
Wall, flange and floor mountable
Temperature of the
running environment
-10–50°C , derate above 40°C
Average non-fault time
2 years (25°C ambient temperature)
Protective degree
IP20
Cooling
Air-cooling
