INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
161
Function
code
Name
Detailed instruction of parameters
Default
value
7: Output power (relative to 2 times the
rated power of the motor)
8: Set torque value (relative to 2 times
the rated torque of the motor)
9: Output torque (relative to 2 times the
rated torque of the motor)
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: Input value of high-speed pulse HDI
14: Modbus communication set value 1
15: Modbus communication set value 2
16: Set value 1 of PROFIBUS/CANopen
communication
17: Set value 2 of PROFIBUS/CANopen
communication
18: Set value 1 of Ethernet
communication
19: Set value 2 of Ethernet
communication
20–21: Reserved
22: Torque current (corresponding to
triple the rated current of the motor)
23: Ramp reference frequency (with
sign)
24–30: Reserved
P06.17
Lower output limit of AO1
-100.0%–P06.19
0.0%
P06.18
Corresponding AO1
output of lower limit
0.00V–10.00V
0.00V
P06.19
Upper output limit of AO1
P06.17–100.0%
100.0%
P06.20
The corresponding AO1
output of upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22
Lower output limit of AO2
-100.0%–P06.24
0.0%
P06.23
Corresponding AO2
output of lower limit
0.00V–10.00V
0.00V
P06.24
Upper output limit of AO2
P06.22–100.0%
100.0%
