INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
172
Set value
Function
Instructions
value is 1 and output the signal of OFF if the set
value is 0.
26
DC bus voltage
establishment finished
The output is vlaid when the bus voltage reaches the
undervoltage point of the inverter.
27–30
Reserved
Related parameters
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0: Open collector high-speed pulse
output
1: Open collector output
0
P06.01
Y output
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Set count value reached
19: Specified count value reached
20: External fault valid
21: Length arrival
22: Running time arrival
23: Modbus communication virtual
terminals output
24: PROFIBUS/CANopen
communication virtual terminals output
0
P06.02
HDO output
0
P06.03
Relay RO1 output
1
P06.04
Relay RO2 output
5
