Goodrive300 Series VFD Basic operation instruction
171
VFD is the upper limit frequency.
Lower-limit frequency arrival
Output ON signal when the running frequency of the
VFD is the lower limit frequency.
When the main circuit and the control circuit is
established and the protection function of the VFD is
not active. The VFD is in the running state and it will
output ON signal.
Output ON signal when the VFD is in the pre-exciting
state.
Output ON signal if the VFD is beyond the pre-alarm
point. Refer to P11.08–P11.10 for the detailed
instruction.
Output ON signal if the VFD is beyond the pre-alarm
point. Refer to P11.11–P11.12 for the detailed
instruction.
Simple PLC stage
completion
Output signal if the simple PLC stage is completed.
Simple PLC cycle
completion
Output signal if the simple PLC cycle is completed.
Output ON signal if the detected counting exceeds
the set value of P08.25.
Output ON signal if the detected counting exceeds
the set value of P08.26.
Output ON signal if external fault occurs.
Output ON signal if the actual detected length
exceeds the set length by P08.19.
Output ON signal if the accumulative running time of
the VFD exceeds the setting time by P08.27.
Modbus communication
virtual terminal output
Output corresponding signal according to the setting
value of Modbus. Output ON signal if the setting
value is 1 and output OFF signal if the setting value
is 0.
POROFIBUS communication
virtual terminal output
Output a corresponding signal according to the set
value of PROFIBUS/CANOPEN. Output the signal of
ON if the set value is 1 and output the signal of OFF
if the set value is 0.
Ethernet communication
Virtual terminal output
Output a corresponding signal according to the set
value of Ethernet. Output the signal of ON if the set
