INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Peripherial options and parts
265
Model
Recommended
cable size (mm
2
)
Connecting cable size (mm
2
)
Terminal
screw
Tightening
torque
(Nm)
RST
UVW
PE
RST
UVW
P1, (+)
PB
(+),(-)
PE
GD300-018G-4
16
16
16–25
16–25
16–25
10–25
M5
2-–2.5
GD300-022G-4
16
16
16–25
16–25
16–25
10–25
M6
4–6
GD300-030G-4
25
16
16–25
16–25
16–25
16–25
M6
4–6
GD300-037G-4
25
16
25–50
25–50
25–50
16–50
M8
9–11
GD300-045G-4
35
16
25–50
25–50
25–50
16–50
M8
9–11
GD300-055G-4
50
25
50–95
50–95
50–95
25–50
M8
9–11
GD300-075G-4
70
35
70–95
70–95
70–95
35–50
M10
18–23
GD300-090G-4
95
50
95–150
95–150
95–150
50–150
M10
18–23
GD300-110G-4
120
70
95–300
95–300
95–300
70–240
M10
18–23
GD300-132G-4
185
95
95–300
95–300
95–300
95–240
It is recommended to
use wrench or
sleeve because
screw is used as
terminal.
GD300-160G-4
240
120
95–300
95–300
95–300
120–240
GD300-200G-4
95×2P
120
95×2P
–150×2P
95×2P
–150×2P
95×2P
–150×2P
120–240
GD300-220G-4
150×2P
150
95×2P
–150×2P
95×2P
–150×2P
95×2P
–150×2P
150–240
GD300-250G-4
95×4P
95×2P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD300-280G-4
95×4P
95×2P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD300-315G-4
95×4P
95×4P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD300-350G-4
95×4P
95×4P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD300-400G-4
150×4P
150×2P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
GD300-500G-4
150×4P
150×2P
95×4P
–150×4P
95×4P
–150×4P
95×4P
–150×4P
95×2P
–150×2P
Note:
1. Cables of the sizes recommended for the main circuit can be used in scenarios where the ambient
temperature is lower than 40°C, the wiring distance is shorter than 100 m, and the current is the rated
current.
2. The terminals P1, (+), and (-) are used to connect to DC reactors and brake accessories.
