INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Peripherial options and parts
267
Model
Recommended
cable size (mm
2
)
Connecting cable size (mm
2
)
Terminal
screw
Tightening
torque
(Nm)
RST
UVW
PE
RST
UVW
P1,(+)
PB
(+),(-)
PE
GD300-200G-6
120
70
95–300
70–300
35–300
70–240
sleeve because
screw is used as
terminal.
GD300-220G-6
185
95
95–300
70–300
35–300
95–240
GD300-250G-6
185
95
95–300
70–300
35–300
95–240
GD300-280G-6
240
120
95–300
95–300
70–300
120–240
GD300-315G-6
95×2P
95
95–150
70–150
70–150
35–95
GD300-350G-6
95×2P
95
95–150
70–150
70–150
35–95
GD300-400G-6
150×2P
150
95–150
70–150
70–150
50–150
GD300-500G-6
95×4P
95×2P
95–150
70–150
70–150
70–150
GD300-560G-6
95×4P
95×4P
95–150
70–150
70–150
70–150
GD300-630G-6
150×4P
150×2P
95–150
70–150
70–150
70–150
Note:
1. Cables of the sizes recommended for the main circuit can be used in scenarios where the ambient
temperature is lower than 40°C, the wiring distance is shorter than 100 m, and the current is the rated
current.
2. The terminals P1, (+), and (-) are used to connect to DC reactors and brake accessories.
D.4.3 Routing the cables
Route the motor cable away from other cable routes. Motor cables of several drives can be run in
parallel installed next to each other. It is recommended that the motor cable, input power cable and
control cables are installed on separate trays. Avoid long parallel runs of motor cables with other
cables to decrease electromagnetic interference caused by the rapid changes in the drive output
voltage.
Where control cables must cross power cables make sure that they are arranged at an angle as near
to 90 degrees as possible.
The cable trays must have good electrical bonding to each other and to the grounding electrodes.
Aluminum tray systems can be used to improve local equalizing of potential.
A figure of the cable routing is shown below.
