Goodrive300 Series VFD Function parameters
45
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
P00.09
Combination
of setting
sources
0: A, the current frequency setting is A freauency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max(A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note: The combination manner can be shifted by
P5 (terminal function).
0
○
P00.10
Keypad set
frequency
When A and B frequency commands are selected
as "keypad setting", the value of the function code
is the original setting one of the frequency data of
the VFD.
Setting range: 0.00 Hz–P00.03 (Max. frequency)
50.00
Hz
○
P00.11
ACC time 1
ACC time means the time needed if the VFD
speeds up from 0Hz to the Max. One (P00.03).
DEC time means the time needed if the VFD
speeds down from the Max. Output frequency to
0Hz (P00.03).
Goodrive300 series VFDs define four groups of
ACC/DEC time which can be selected by P05.
The factory default ACC/DEC time of the VFD is
the first group.
Setting range of P00.11 and P00.12: 0.0–3600.0s
Depend
on
model
○
P00.12
DEC time 1
Depend
on
model
○
P00.13
Running
direction
0: Runs at the default direction, the VFD runs in
the forward direction. FWD/REV indicator is off.
1: Runs at the reverse direction, the VFD runs in
0
○
