SV-DA200 series AC servo drive Function codes
-135-
P3.01
1
Input configuration of digital 2
Setting range
Default
Unit
Available mode
0x000–0x136
0x00D
-
P
S
T
P3.02
1
Input configuration of digital 3
Setting range
Default
Unit
Available mode
0x000–0x136
0x004
-
P
S
T
P3.03
1
Input configuration of digital 4
Setting range
Default
Unit
Available mode
0x000–0x136
0x016
-
P
S
T
P3.04
1
Input configuration of digital 5
Setting range
Default
Unit
Available mode
0x000–0x136
0x019
-
P
S
T
P3.05
1
Input configuration of digital 6
Setting range
Default
Unit
Available mode
0x000–0x136
0x01A
-
P
S
T
P3.06
1
Input configuration of digital 7
Setting range
Default
Unit
Available mode
0x000–0x136
0x001
-
P
S
T
P3.07
1
Input configuration of digital 8
Setting range
Default
Unit
Available mode
0x000–0x136
0x002
-
P
S
T
P3.08
1
Input configuration of digital 9
Setting range
Default
Unit
Available mode
0x000–0x136
0x007
-
P
S
T
P3.09
1
Input configuration of digital 10
Setting range
Default
Unit
Available mode
0x000–0x136
0x008
-
P
S
T
These parameters are used to set the input function of digital value 2–10, and they are hex
numbers.
The setting method is the same as P3.00.
Note: The default value is the function selection corresponds to position mode.
P3.01
1
Data size
16bit
Data format
HEX
Modbus address
1602, 1603
CANopen address
0x2301, 0x00
P3.02
1
Data size
16bit
Data format
HEX
Modbus address
1604, 1605
CANopen address
0x2302, 0x00
P3.03
1
Data size
16bit
Data format
HEX
Modbus address
1606, 1607
CANopen address
0x2303, 0x00
P3.04
1
Data size
16bit
Data format
HEX
Modbus address
1608, 1609
CANopen address
0x2304, 0x00
P3.05
1
Data size
16bit
Data format
HEX
Modbus address
1610, 1611
CANopen address
0x2305, 0x00
P3.06
1
Data size
16bit
Data format
HEX
Modbus address
1612, 1613
CANopen address
0x2306, 0x00
P3.07
1
Data size
16bit
Data format
HEX
Modbus address
1614, 1615
CANopen address
0x2307, 0x00
P3.08
1
Data size
16bit
Data format
HEX
Modbus address
1616, 1617
CANopen address
0x2308, 0x00
P3.09
1
Data size
16bit
Data format
HEX
Modbus address
1618, 1619
CANopen address
0x2309, 0x00
